Tiger-Vac 2D-1 (PCS-WM) HEPA ORDLOC Type H

HEPA H14 decontamination station for lead and gunpowder dust

Tiger-Vac 2D-1 (PCS-WM) HEPA ORDLOC Type H is a wall-mounted personal cleaning station designed for decontamination of clothing and equipment at indoor shooting ranges. It safely removes lead and gunpowder dust directly in the changing area – preventing contamination from leaving the facility. Equipped with certified H14 HEPA filtration and ESD-safe accessories, it protects both users and surroundings.

Ordinary Location – extraordinary protection

This model is intended for use in non-classified (ORDLOC) areas where the risk is not explosion but toxic dust exposure. It is tested according to EN 1822 and IEST-RP-CC001 and includes an aerosol leak-tested HEPA H14 filter (99.995 % @ 0.3 µm MPPS). The stainless-steel housing and conductive accessories ensure complete tightness, grounding, and long-term reliability.

Why a standard vacuum is not enough

The EU exposure limit for airborne lead is 0.03 mg/m³ – yet levels on indoor ranges are often 20–30 times higher. Conventional vacuums recirculate fine particles and lack certified filtration or leakage control. The Tiger-Vac 2D-1 removes the hazard at the source – before it leaves the range – making decontamination a natural part of every routine.

Compact, practical, and user-friendly

The unit mounts on the wall but can also be removed and used as a portable HEPA vacuum. The 8 L stainless-steel recovery tank is lightweight and easy to handle, and the conductive hose and disposable collection bags ensure safe and efficient operation. Ideal for locker rooms, airlocks, and exit zones.

Applications

Primary:

• Shooting-range exit areas
• Changing rooms and airlocks
• Personnel zones with lead-dust exposure

Additional:

• Decontamination of clothing, footwear, and equipment
• Prevention of “take-home lead” contamination
• Laboratories and facilities handling toxic dust

Technical note

Tiger-Vac 2D-1 (PCS-WM) HEPA ORDLOC fully meets the technical requirements for a Type H vacuum cleaner in accordance with EN 60335-2-69 (Annex AA) and EN 1822 (H14). It can therefore be legitimately and professionally classified and marketed as Type H based on the following criteria:

• Filtration: Equipped with a HEPA H14 filter (99.995 % at 0.3 µm), tested per EN 1822 and IEST-RP-CC001 (MPPS method) – an explicit requirement in Annex AA for “Dust Class H”.
• Construction: The complete air path – tank, seals, and housing – is metallic and leak-tested; every unit is aerosol-tested before shipment as documented by the manufacturer.
• Purpose: Developed for the collection of toxic and hazardous dust (lead, antimony, gunpowder) in non-classified areas, exactly as defined in Annex AA for “High Hazard Dusts”.
• Documentation: Technical data and manufacturer literature reference EN 1822, IEST-RP-CC001, and OSHA guidelines, providing full compliance evidence. No notified-body certification is required since the standard falls under the Low Voltage Directive, not ATEX.

Conclusion: The Tiger-Vac 2D-1 (PCS-WM) HEPA ORDLOC Type H is approved and documented for the safe collection of toxic dust in non-classified environments – the ideal solution for lead and gunpowder contamination control at shooting ranges.
