Food/Pharma · EU 10/2011

AIRDUC® PE 362 FOOD (MD)

Suction and pressure hose in polyethylene, food-grade certified per FDA 21 CFR 177.1520 3.1 + 3.2 as well as EU 10/2011 and EC 1935/2004. Manufactured per (GMP) EU 2023/2006. Designed for transport of dry foods, powders and granulates in food, pharma and chemical industries. PE material's broad chemical resistance combined with food-grade approval makes the hose usable on multi-purpose installations where both food and chemical media must be handled.

Download datasheet (PDF)

FDA + EU 10/2011 GMP EU 2023/2006 −35 to +80 °C Chemical-resistant PE

FDA + EU 10/2011
GMP EU 2023/2006
−35 to +80 °C
Chemical-resistant
Suction + pressure
Cut to length

Why this hose?

AIRDUC® PE 362 FOOD (MD) is the food-grade version of the PE 362 range. PE is one of the few polymers that's both food-grade certifiable and broadly chemically resistant — this makes the hose particularly usable on multi-medium installations where the medium can alternate between foods and chemical ingredients.

GMP EU 2023/2006 (Good Manufacturing Practice) is a plus signal documenting that the manufacturer has strict quality processes in the manufacturing itself — especially important in pharma applications where traceability is critical.

Where it is used

In food industry the hose typically sits on powder and granulate handling — especially bulk-bag charging and discharging where large amounts of powder are pneumatically moved between silos and production equipment.

In pharma it's used for powder transport between raw material receiving and production lines. PE's broad chemical resistance covers both food-compatible and lightly aggressive pharmaceutical ingredients.

In everyday talk we call it a "food PE" — it's the natural food-grade variant of the PE 362 range.

Technical specifications

Technical specifications for AIRDUC® PE 362 FOOD (MD).

Material	Polyethylene (PE) food-grade
Temperature	−35 to +80 °C
Food-grade	FDA 21 CFR 177.1520 3.1+3.2, EU 10/2011, EC 1935/2004
Manufacturing	GMP EU 2023/2006
Conformity	FDA, EU 10/2011, EC 1935/2004, GMP, REACH, RoHS
Cut to length	Yes
Manufacturer SKU group	3620000

Dimensions and ordering

Standard dimensions for AIRDUC® PE 362 FOOD (MD).

Dimensions, pressure and vacuum data for AIRDUC® PE 362 FOOD (MD)
Inner Ø [mm]	Outer Ø [mm]	Wall thickness [mm]	Working pressure DIN 26057, 10 % elong. [bar]	Vacuum axially fixed [bar]	Bend radius [mm]	Max. length [m]	Weight [kg/m]	Roll [m]	Article no.
25	31	0.6	1.455	0.57	17	15	0.22	10	36200250000
28	34	0.6	1.375	0.54	20	15	0.25	10	36200280000
30	38	0.6	0.98	0.52	22	15	0.22	—	36200300000
32	40	0.6	0.92	0.505	23	15	0.23	—	36200320000
38	46	0.6	0.78	0.475	26	15	0.27	10	36200380000
40	48	0.6	0.74	0.46	27	15	0.28	10	36200400000
45	53	0.6	0.66	0.43	30	15	0.32	—	36200450000
50.5	58.5	0.6	0.595	0.395	32	15	0.35	10	36200500000
55	63	0.6	0.54	0.35	35	15	0.38	—	36200550000
60	68	0.6	0.5	0.32	37	15	0.41	10	36200600000
64.5	72.5	0.6	0.46	0.275	40	15	0.44	10	36200650000
70	78.5	0.6	0.43	0.23	44	15	0.56	10	36200700000
75	83.5	0.6	0.4	0.21	47	15	0.6	10	36200750000
80	88.5	0.6	0.375	0.2	49	15	0.64	10	36200800000
90	98.5	0.6	0.335	0.17	54	15	0.72	10	36200900000
100	109	0.6	0.3	0.135	59	15	0.79	10	36201000000
110	118.5	0.6	0.275	0.12	64	15	0.87	10	36201100000
120	128.5	0.6	0.25	0.115	69	15	0.94	—	36201200000
126.5	135	0.6	0.24	0.09	72	15	0.99	10	36201250000
130	139	0.6	0.2	0.09	80	15	1.02	—	36201300000
151.5	160	0.6	0.2	0.09	84	10	1.18	—	36201500000
160	168.5	0.6	0.19	0.075	89	10	1.25	—	36201600000
180	189	0.6	0.15	0.06	101	10	1.4	—	36201800000
202.3	212.3	0.6	0.15	0.06	110	15	1.58	—	36202000000
250	260	0.6	0.12	0.025	135	15	1.94	—	36202500000

Fields without a value (—) are not specified in the manufacturer's factsheet. Overpressure and underpressure values are recommended operating limits; the product can be subjected to higher loads on request. Bend radius is measured along the inside of the hose bend.

Standards and compliance

AIRDUC® PE 362 FOOD (MD) is certified to:

FDA 21 CFR 177.1520 3.1 and 3.2. US standard for food contact materials.
EU 10/2011 + EC 1935/2004. European directives for materials in contact with food.
(GMP) EU 2023/2006. Good Manufacturing Practice for food contact materials.
REACH and RoHS. EU directives for chemicals.

Documentation and downloads

Additional documents about this hose, its compliance and installation. Click to download as PDF in a new tab.

Datasheet (Particulair) Our 4-page datasheet with specifications, dimension table, applications and contact info. PDF REACH declaration Manufacturer declaration of REACH compliance (EC 1907/2006). PDF · 2026 RoHS declaration Manufacturer declaration of RoHS directive compliance. PDF · 2025 ISO 9001 certificate Quality management certificate for the production. PDF Installation guidelines General installation guidelines. PDF · 2025 Chemical resistance table Manufacturer's overview of chemical resistance for materials, organised by medium. PDF · 2025

Help with material selection

Although this hose isn't ATEX-relevant, these two articles provide useful background on electrical resistance and industrial safety — important if you later combine the hose with electrical equipment or work in mixed environments:

ESD

The invisible weakest link

Why a conductive or antistatic hose isn't sufficient on its own — and what grounding means for the complete system.

Read the article

ESD

Know your ohm

The difference between antistatic and conductive, which resistance limits apply where, and how to measure them correctly.

Read the article

Industries that use it

AIRDUC® PE 362 FOOD (MD) is used across food, pharma and chemical industries:

In food industry it's standard on powder pneumatic systems — bulk-bag charging, silo unloading, dosing. The food-grade approval combined with PE's abrasion resistance makes the hose suitable for continuous operation.

In pharma the GMP manufacturing and fullness of certifications (FDA + EU + GMP) is decisive for compliance documentation.

Custom lengths and assemblies

The hose is delivered on 10 m and 20 m rolls. We cut to length and fit hygiene couplings or standard fittings.

For serial use in food production we can establish consistent assembly with documented food-grade compliance.

See our custom hose assemblies

Related hoses

Hoses often considered alongside this one. Suggestions are based on the same category and similar properties.

Frequently asked questions

What's the difference between AIRDUC® PE 362 FOOD and AIRDUC® PE 362 EC?

FOOD is food-grade certified (FDA + EU 10/2011 + GMP). EC is ATEX-conductive (<10³ Ω) for explosion hazard zones. Choose FOOD for food production; choose EC for ATEX applications. Both have the same PE base material.

What does FDA 21 CFR 177.1520 mean?

US regulation for olefin-based polymers in contact with food. Section 3.1 and 3.2 are specific for polyethylene types. The material passes when it meets the specified tests for migration and toxicology.

Does it tolerate wet and hot cleaning?

Yes, up to +80 °C continuous. This covers normal CIP cleaning. For SIP (Steam-In-Place) at higher temperatures choose a silicone hose (NORFLEX® SIL 408 up to +180 °C).

Is it ATEX-approved?

No, the FOOD version is insulating. For ATEX zones choose AIRDUC® PE 362 EC.

Does it tolerate food-based acids?

PE is compatible with most diluted food acids (citric, acetic, lactic) at operating temperatures. For specific high-concentrated acids cross-check against the resistance table.

Can I get it with hygiene couplings?

Yes. We fit SMS, DIN 11851, Tri-Clamp or other hygiene couplings as a finished assembly. Tell us which system your food production uses.
